F Series Parallel Shaft Helical Gear Motor Speed Reducer with High Overload Capacity Low Energy Consumption and High Efficiency

Place of Origin : Henan, China

Brand Name : HUAGONG

Price : CN¥1,393.72/sets 1-4 sets

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Warranty : 1 Year

Contact Now

Flange Hollow Shaft Heavy Duty F Series Parallel Shaft Helical Worm Gear Motor Speed Reducer
Product Overview
The F Series Parallel Shaft Helical Worm Gear Motor Speed Reducer is engineered to international technical standards, delivering exceptional performance and reliability for demanding industrial applications.
Key Features & Benefits
  • Manufactured to international technical standards with advanced engineering
  • Space-saving design with reliable, durable construction and high overload capacity
  • Power capacity up to 90KW and beyond for heavy-duty applications
  • Low energy consumption with superior performance and efficiency exceeding 95%
  • Minimal vibration and noise levels with high energy-saving capabilities
  • Constructed with premium section steel materials and steel cast iron housing
  • Gear surfaces treated with high-frequency heat treatment for enhanced durability
  • Precision machining ensures accurate shaft parallelism and positioning
  • Integrated mechatronic design compatible with various motor types
  • Consistent quality and stable performance characteristics
Technical Parameters
Input power rating and permissible torque
Size 37 47 57 67 77 87 97 107 127 157
Structure F FA FF FAF FAZ
Input power rating(kw) 0.18~3 0.18~3 0.18~5.5 0.18~5.5 0.37~11 0.75~22 1.1~30 2.2~45 7.5~90 11~200
Ratio 3.81~128.51 5.06~189.39 5.18~199.70 4.21~228.99 4.30~281.71 4.12~270.68 4.68~280.76 6.20~254.40 4.63~172.17 11.92~267.43
Permissible torque 200 400 600 820 1500 3000 4300 7840 12000 18000

Gear unit weight

Size 37 47 57 67 77 87 97 107 127 157
Weight (kg) 13 18 34 55 90 150 260 402 700 950
The weights are mean values,only for reference

Product Details & Specifications
F Series Parallel Shaft Helical Gear Motor Speed Reducer with High Overload Capacity Low Energy Consumption and High Efficiency F Series Parallel Shaft Helical Gear Motor Speed Reducer with High Overload Capacity Low Energy Consumption and High Efficiency F Series Parallel Shaft Helical Gear Motor Speed Reducer with High Overload Capacity Low Energy Consumption and High Efficiency F Series Parallel Shaft Helical Gear Motor Speed Reducer with High Overload Capacity Low Energy Consumption and High Efficiency F Series Parallel Shaft Helical Gear Motor Speed Reducer with High Overload Capacity Low Energy Consumption and High Efficiency F Series Parallel Shaft Helical Gear Motor Speed Reducer with High Overload Capacity Low Energy Consumption and High Efficiency F Series Parallel Shaft Helical Gear Motor Speed Reducer with High Overload Capacity Low Energy Consumption and High Efficiency F Series Parallel Shaft Helical Gear Motor Speed Reducer with High Overload Capacity Low Energy Consumption and High Efficiency F Series Parallel Shaft Helical Gear Motor Speed Reducer with High Overload Capacity Low Energy Consumption and High Efficiency F Series Parallel Shaft Helical Gear Motor Speed Reducer with High Overload Capacity Low Energy Consumption and High Efficiency F Series Parallel Shaft Helical Gear Motor Speed Reducer with High Overload Capacity Low Energy Consumption and High Efficiency
